SHIMANO
SAINT – Rear FREEHUB – CENTER LOCK – Disc Brake – 135×10/12 mm Thru Axle –
11-speed
With
quick engagement, angular contact bearings, and quality sealing, the SHIMANO
SAINT freehub is perfect for all gravity MTB applications
PRODUCT SPECIFICATIONS
| MODEL NO |
FH-M820 |
| SERIES |
SAINT M820 Series |
| Color |
Series color |
| Average weight |
347 (φ10) 333 (φ12) |
| Remarks |
* For straight spoke, Lacing pattern limited to 3-cross, non-offset rim For details, refer to Products Technical Information |
| Color|1 Hub shell |
Series color |
| Brake type |
CENTER LOCK disc brake |
| Rear speeds |
11/10/9/8 – 11/10/9/8 |
| O.L.D. (mm) |
135 – 135 |
| Spoke hole|32H |
✔ |
| Spoke hole|36H |
✔ |
| External serration disc brake rotor lock ring|With |
✔ |
| Internal serration disc brake rotor lock ring|Without |
✔ |
| Axle fixing method |
Thru |
| Thru axle (length x inner diameter ; mm)|135 x 10 |
✔ |
| Thru axle (length x inner diameter ; mm)|135 x 12 |
✔ |
| Flange distance (mm) |
57.4 | 57.4 |
| Offset (mm) |
6.4 | 6.4 |
| P.C.D. left / right (mm) |
44/45 | 44/45 |
| Flange diameter left / right (mm) |
52.8/53.8 | 52.8/53.8 |
| Spline type|HG spline M (10/9/8-speed, MTB 11-speed) |
✔ |
| Engagement type |
Pawl ratchet |
| Quick engagement |
X (more than 36 times/360 deg.) | X (more than 36 times/360 deg.) |
| Seal|Hub |
Labyrinth+Contact – Labyrinth+Contact |
| Seal|FREEHUB body |
Contact – Contact |
| Internal grease sleeve |
✔ |
